•Off road condition, in hard mining.
•All position for dump and earthmover.
•Design emphasis on Traction and Chip & Cut performance.
| Benefits | Vehicle |
|---|---|
 |
 |
•Off road condition, in hard mining.
•All position for dump and earthmover.
•Design emphasis on Traction and Chip & Cut performance.
| Size | Ply Rating | Spd | Load Index (single/double) | Measure Rim (inch) | Max Load(kg) | Pressure(Kpa) | Inflated Dimensions | Tread Depth (mm) | Min. DualSpacin g (mm) | |||
| Single | Dual | Single | Dual | SW | OD | |||||||
| 7.50R16LT | 14 | L | 122/118 | 6.00G | 1500 | 1320 | 770 | 770 | 215 | 805 | 14.00 | 255 |
| 8.25R16LT | 16 | L | 128/124 | 6.50H | 1800 | 1600 | 770 | 770 | 235 | 855 | 14.50 | 278 |
| 10.00R20 | 18 | K | 149/146 | 7.50 | 3250 | 3000 | 930 | 930 | 278 | 1055 | 16.50 | 328 |
| 11.00R20 | 18 | K | 152/149 | 8.00 | 3550 | 3250 | 930 | 930 | 293 | 1085 | 17.00 | 346 |
| 12.00R20 | 18 | K | 154/151 | 8.50 | 3750 | 3450 | 830 | 830 | 315 | 1125 | 18.00 | 372 |
| 13.00R25NHS TT | A2 | 182 | 10.00/1.5 | 8500 | 950 | 345 | 1302 | 26.00 | ||||
| 13.00R25NHS TT | B | 182 | 10.00/1.5 | 8500 | 950 | 345 | 1302 | 26.00 | ||||
