•Suitable for all wheel position of middle/long-distance trucks on various road conditions.
•3 zigzag grooves combine with lateral sipes on shoulder provides excellent traction and prevents hydroplaning.
| Benefits | Vehicle |
|---|---|
 |
 |
•Suitable for all wheel position of middle/long-distance trucks on various road conditions.
•3 zigzag grooves combine with lateral sipes on shoulder provides excellent traction and prevents hydroplaning.
| Size | Ply Rating | Spd | Load Index (single/double) | Measure Rim (inch) | Max Load(kg) | Pressure(Kpa) | Inflated Dimensions | Tread Depth (mm) | Min. DualSpacin g (mm) | |||
| Single | Dual | Single | Dual | SW | OD | |||||||
| 7.00R16LT | 14 | M | 118/114 | 5.50F | 1320 | 1180 | 770 | 770 | 200 | 775 | 11.00 | 236 |
| 7.50R16LT | 14 | L | 122/118 | 6.00G | 1500 | 1320 | 770 | 770 | 215 | 805 | 14.00 | 255 |
| 8.25R16LT | 16 | L | 128/124 | 6.50H | 1800 | 1600 | 770 | 770 | 235 | 855 | 14.50 | 278 |
| 8.25R20 | 16 | K | 139/137 | 6.50 | 2430 | 2300 | 930 | 930 | 232 | 971 | 15.50 | 274 |
| 9.00R20 | 16 | K | 144/142 | 7.00 | 2800 | 2650 | 900 | 900 | 259 | 1018 | 15.50 | 306 |
| 10.00R20 | 18 | K | 149/146 | 7.50 | 3250 | 3000 | 930 | 930 | 278 | 1055 | 16.50 | 328 |
| 11.00R20 | 18 | K | 152/149 | 8.00 | 3550 | 3250 | 930 | 930 | 293 | 1085 | 17.00 | 346 |
| 11.00R22 | 16 | K | 152/149 | 8.00 | 3550 | 3250 | 830 | 830 | 293 | 1135 | 17.00 | 346 |
| 12.00R20 | 18 | K | 154/151 | 8.50 | 3750 | 3450 | 830 | 830 | 315 | 1125 | 18.00 | 372 |
| 12.00R20 | 20 | K | 156/153 | 8.50 | 4000 | 3650 | 900 | 900 | 315 | 1125 | 18.00 | 372 |
| 12.00R24 | 20 | K | 160/157 | 8.50 | 4500 | 4125 | 900 | 900 | 315 | 1222 | 17.50 | 372 |
| 11R22.5 | 16 | M | 146/143 | 8.25 | 3000 | 2725 | 830 | 830 | 279 | 1050 | 17.00 | 320 |
| 12R22.5 | 18 | K | 152/149 | 9.00 | 3550 | 3250 | 830 | 830 | 300 | 1084 | 17.00 | 343 |
| 13R22.5 | 18 | L | 154/151 | 9.75 | 3750 | 3450 | 830 | 830 | 320 | 1124 | 18.00 | 360 |
| 11R24.5 | 14 | L | 146/143 | 8.25 | 3000 | 2725 | 720 | 720 | 279 | 1104 | 17.00 | 318 |
| 11R24.5 | 16 | L | 149/146 | 8.25 | 3250 | 3000 | 830 | 830 | 279 | 1104 | 17.00 | 318 |
| 295/75R22.5 | 14 | L | 144/141 | 9.00 | 2800 | 2575 | 760 | 760 | 298 | 1014 | 17.00 | 335 |
| 295/75R22.5 | 16 | L | 146/143 | 9.00 | 3000 | 2725 | 830 | 830 | 298 | 1014 | 17.00 | 335 |
| 315/80R22.5 | 18 | M | 154/151 | 9.00 | 3750 | 3450 | 830 | 830 | 312 | 1076 | 17.00 | 351 |
| 315/80R22.5 | 20 | K | 157/154 | 9.00 | 4125 | 3750 | 900 | 900 | 312 | 1076 | 17.00 | 351 |
| 285/75R24.5 | 14 | L | 144/141 | 8.25 | 2880 | 2575 | 760 | 760 | 283 | 1050 | 17.00 | 318 |
| 285/75R24.5 | 16 | L | 147/144 | 8.25 | 3075 | 2800 | 830 | 830 | 283 | 1050 | 17.00 | 318 |
