•Suitable for all wheel position of middle/long-distance buese and steerinig wheel position of trucks on good road conditions.
•4 zigzag longitudinal grooves provides excellent directional driving performance.
| Benefits | Vehicle |
|---|---|
 |
 |
•Suitable for all wheel position of middle/long-distance buese and steerinig wheel position of trucks on good road conditions.
•4 zigzag longitudinal grooves provides excellent directional driving performance.
| Size | Ply Rating | Spd | Load Index (single/double) | Measure Rim (inch) | Max Load(kg) | Pressure(Kpa) | Inflated Dimensions | Tread Depth (mm) | Min. DualSpacin g (mm) | |||
| Single | Dual | Single | Dual | SW | OD | |||||||
| 7.50R16LT | 14 | L | 122/118 | 6.00G | 1500 | 1320 | 770 | 770 | 215 | 805 | 14.00 | 255 |
| 8.25R16LT | 16 | L | 128/124 | 6.50H | 1800 | 1600 | 770 | 770 | 235 | 855 | 14.00 | 278 |
| 8.25R20 | 16 | K | 139/137 | 6.50 | 2430 | 2300 | 930 | 930 | 232 | 971 | 14.50 | 274 |
| 10.00R20 | 18 | K | 149/146 | 7.50 | 3250 | 3000 | 930 | 930 | 278 | 1055 | 17.00 | 328 |
| 11.00R20 | 18 | K | 152/149 | 8.00 | 3550 | 3250 | 930 | 930 | 293 | 1085 | 17.50 | 346 |
| 12.00R20 | 18 | K | 154/151 | 8.50 | 3750 | 3450 | 830 | 830 | 315 | 1125 | 17.50 | 372 |
| 11R22.5 | 16 | M | 146/143 | 8.25 | 3000 | 2725 | 830 | 830 | 279 | 1050 | 16.50 | 320 |
